[7ZT7A00537] ThinkSystem Intel X710-DA2 PCIe 10Gb 2-Port SFP+ Ethernet Adapter

Specifications

Processor / Memory
Processor 1 x Intel X710
m SR590 ¦ Lenovo ThinkSystem SR630 ¦ Lenovo ThinkSystem SR645 7D2X ¦ Lenovo ThinkSystem SR650 ¦ Lenovo ThinkSystem SR665 7D2V ¦ Lenovo ThinkSystem SR670 7Y37 ¦ Lenovo ThinkSystem SR850 ¦ Lenovo ThinkSystem SR860 ¦ Lenovo ThinkSystem SR950 ¦ Lenovo ThinkSystem ST250 ¦ Lenovo ThinkSystem ST550
Miscellaneous
Included Accessories Low-profile bracket
Compliant Standards C-Tick, EN 61000-3-2, EN55022, EN 61000-3-3, EN55024, RoHS, UL 94 V-1, AS/NZS CISPR 22, ICES-003 issue 4, FCC CFR47 Part 15 A
Networking
Ports 10 Gigabit SFP+ x 2
Connectivity Technology Wired
Data Link Protocol 10 Gigabit Ethernet
Data Transfer Rate 10 Gbps
Capacity Jumbo frame size: 9728
Remote Management Protocol SNMP, RMON
Features Flow control, TCP/IP offloading, Virtual Machine Device Queues (VMDq), teaming support, PXE support, Large Send Offload (LSO), Receive Side Scaling (RSS), Single Root I/O Virtualization (SR-IOV), adaptive load balancing (ALB), Extended Message-Signaled Interrupts (MSI-X), UDP/IP offloading, Virtual Ethernet Port Aggregator (VEPA), Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE)
Compliant Standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1Qbg, IEEE 802.1Qbh, IEEE 1588-2008

Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 131 °F
Humidity Range Operating 10 - 90%
General
Device Type Network adapter
Form Factor Plug-in card - low profile
Interface (Bus) Type PCI Express 3.0 x8
Expansion / Connectivity
Interfaces 2 x 10Gb Ethernet - SFP+
