Ports Gigabit Ethernet x 4
Connectivity Technology Wired
Data Link Protocol Gigabit Ethernet
Capacity Jumbo frame size: 9600
Features Flow control, Jumbo Frames support, teaming support, PXE support, Receive Side Scaling (RSS), Extended Message-Signaled Interrupts (MSI-X), Transmit Side Scaling (TSS), iSCSI boot, TCP/IP checksum offload, UDP/IP checksum offload, Message Signaled Interrupts (MSI)
Compliant Standards IEEE 802.1Q, IEEE 802.3x
Dimensions & Weight
Width 0.7 in
Depth 5.2 in
Height 2.7 in
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 131 °F
Humidity Range Operating 20 - 80% (non-condensing)
General
Device Type Network adapter
Form Factor Plug-in card - low profile
Interface (Bus) Type PCI Express 2.0 x4
Expansion / Connectivity
Interfaces 4 x network - RJ-45
