[4XC7A08277] ThinkSystem Intel I350 1GbE RJ45 4-port OCP Ethernet Adapter

Specifications

Processor / Memory
Processor 1 x Intel I350

Networking
Ports 1000Base-T x 4
Connectivity Technology Wired
Cabling Type Ethernet 1000Base-T
Data Link Protocol Gigabit Ethernet
Data Transfer Rate 1 Gbps
Capacity Jumbo frame size: 9500
Features Wake on LAN (WOL), auto-uplink (auto MDI/MDI-X), Intel I/O Acceleration Technology (I/OAT), Virtual Machine Device Queues (VMDq), PXE support, Receive Side Scaling (RSS), Single Root I/O Virtualization (SR-IOV), Intel QuickData Technology, Extended Message-Signaled Interrupts (MSI-X), TCP/IP checksum offload, Virtual Ethernet Port Aggregator (VEPA), Message Signaled Interrupts (MSI)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az, IEEE 1588-2008

Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 131 °F
Humidity Range Operating 5 - 85% (non-condensing)
General
Device Type Network adapter
Form Factor Plug-in card
Interface (Bus) Type Open Compute Project mezzanine (OCP) 3.0
Expansion / Connectivity
Interfaces 4 x 1000Base-T - RJ-45
