[867334-B21] HPE Ethernet 10/25Gb 2-port FLR-SFP28 QL41401-A2G Converged Network Adapter

Specifications

Processor / Memory
Processor Cavium QL41401

Miscellaneous
Compliant Standards WHQL, RoHS, CE/EMC
Networking
Ports 25 Gigabit SFP28 x 2
Connectivity Technology Wired
Data Link Protocol 10 Gigabit Ethernet, 25 Gigabit Ethernet
Data Transfer Rate 25 Gbps
Performance Bidirectional throughput: 100 Gbps
Capacity Jumbo frame size: up to 9.2 KB
Remote Management Protocol SNMP
Features VLAN support, wake on LAN (WOL), IPv6 support, Jumbo Frames support, PXE support, Receive Side Scaling (RSS), Single Root I/O Virtualization (SR-IOV), Precision Time Protocol (PTP), RDMA over Converged Ethernet (RoCE), Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE), RDMA over Converged Ethernet (RoCE) v2, Receive Side Coalescing (RSC), HPE Sea of Sensors 3D, Mware NetQueue and Microsoft Virtual Machine Queue (VMQ), iSCSI Extensions over RDMA (iSER)
Compliant Standards IEEE 802.1ad, IEEE 802.1as, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, IEEE 802.3by
Environmental Parameters
Min Operating Temperature 41 °F
Max Operating Temperature 140 °F
Humidity Range Operating 5 - 95% (non-condensing)
General
Device Type Network adapter
Form Factor Plug-in card
Interface (Bus) Type FlexibleLOM
PCI Specification Revision PCIe 3.0
Expansion / Connectivity
Interfaces 2 x 25Gb Ethernet - SFP28
Power
Power Consumption Operational 12.5 Watt
