ST300MP0075 Seagate Enterprise Performance 15K.5 300GB 15000RPM SAS 12Gbps 128MB Cache (SED/ 4Kn) 2.5-inch Internal Hard Drive
Specification : 4K Native
Capacity : 300GB
Interface : 12Gb/s SAS
Average Latency (ms) : 2.0
Sustained Transfer Rate (Outer to Inner Diameter) MiB/s : 246 to 180
Max. Instantaneous Transfer Rate (SAS dual port) MB/s : 2400
Cache, Multisegmented (MB) : 128
NAND Flash Type : eMLC
NAND Flash Size : 32GB
Disks/Heads : 2/4
Nonrecoverable Read Errors per Bits Read, Max : 1 per 10e16
Annualized Failure Rate (AFR) : 0.44%
Typical Op (A) +5V/+12V : 0.46/0.51
Average Idle Power (W) : 4.8
Average Operating Power (W) : 8.4
Ambient Temperature, Operating (C°) : 5 to 55
Ambient Temperature, Nonoperating (C°) : -40 to 70
Temperature Change Rate/Hr, Max (C°) : 20
Relative Humidity, Noncondensing (max gradient 20% hour) : 5% to 95%
Shock, Max Operating: 11ms (Gs) : 40
Shock, Max Nonoperating: 2ms (Gs) : 400
Vibration, Operating: <400Hz (Gs) : 0.5
Vibration, Nonoperating: <500Hz (Gs) : 2.4
Height (in/mm, max) : 0.591/15.00
Width (in/mm, max) : 2.750/69.85
Depth (in/mm, max) : 3.955/100.45
Weight (lb/kg) : 0.496/0.225
